1604

IP Speaker Minuet, 12W PoE

Finished in wood and powered over Ethernet, the new IP 1604 speaker offers exceptional sound. Depending on the connection cable used, we can achieve a power of 12 W (IEEE 802.3 at) or 6 W (IEEE 802.3 af). Perfect for broadcasting pre-recorded or live messages from the 1211 console, announcements and background music. Includes bracket for wall mounting and adhesive feet for table mounting.



Do you have questions about this product? Contact our support:



sat_consultas@egiaudio.com

PTC for tweeter protection.

Manual message playback from 1211 console. Compatible with all Millennium IP software.

PoE power supply simplifies installation.

Self-test and verification of electronics and speaker for correct message broadcasting.

Operating modes:

- Internal audio player (WAV, MP3, internet radio,...).

- IOS compatibility with 1814/DLNA app.

- VoIP client, Unicast or Multicast.

- RTP and SIP protocols.

- Modbus compatibility.

- Event scheduler.

6Gb internal memory to store audio.

Upgradable firmware.

Configuration through web interface accessible from PC, Smartphone or Tablet.

For indoor installation. Includes bracket for horizontal or vertical wall installation, and adhesive feet for desktop installation.

Finish: wood and black metal grille.

Translated with DeepL.com (free version)

1604

Data sheet

Power Supply
PoE
Max power (RMS)
12 W (IEEE 802.3 at); 6 W (IEEE 802.3 af)
Sensitivity (1W/1m)
100 dB
Coverage angle
91º @ 4 KHz; 120º @ 8 KHz
Control software
Software: 1810 Millennium IP Lite, 1811 Millennium IP Pro
Weight
1.7 Kg
Dimensions (mm)
226x150x162
